| Giao diện | 1 10/100Mbps RJ45 Port 1 RJ11 Port 1 USB Port |
|---|---|
| Nút | 1 Power On/Off Switch |
| Bộ cấp nguồn bên ngoài | 5VDC/1A |
| Chuẩn IEEE | IEEE 802.3, 802.3u |
| Chuẩn ADSL | Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite) ITU-T G.994.1 (G.hs), ITU-T G.995.1 , ITU-T G.996.1, ITU-T G.997.1, ITU-T K.2.1 |
| Chuẩn ADSL2 | ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.4 (G.lite.bis) |
| Chuẩn ADSL2+ | ITU-T G.992.5 |
| Kích thước ( R x D x C ) | 5.5*3.6*1.1 in.(140*92*29mm) |
| TÍNH NĂNG PHẦN MỀM | |
|---|---|
| Chất lượng dịch vụ | QoS Remarking based on IPP/ToS, DSCP and 802.1p |
| Bảo mật | NAT Firewall, MAC /IP /URL Filtering |
| IPv6 | IPv6 and IPv4 dual stack Supported IPv6 Tunnels: DS-Lite, 6RD, 6 to 4 Supported IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6 |
| Quản lý | Web Based Configuration(HTTP), Remote management, Telnet management, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools |
| Port Forwarding | Virtual server, DMZ, ACL(Access Control List) |
| VPN Pass-Through | PPTP, L2TP, IPSec Pass-through |
| Giao thức ATM/PPP | ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), PVC - Up to 8 PVCs, |
| Advanced Features | Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt; Dynamic Host Configuration Protocol (DHCP), DHCP relay; Network Address Translation (NAT); Static Routing, RIP v1/v2 (optional); DNS Relay, DDNS IGMP Multicast, UPnP |
| KHÁC | |
|---|---|
| Chứng chỉ | CE, FCC, RoHS |
| Sản phẩm bao gồm | TD-8817 External Splitter RJ-11 Telephone Cable RJ-45 Ethernet Cable USB Cable Quick Installation Guide Resource CD Power Adapter |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™, Windows 7, 8, 10 or MAC® OS, NetWare®, UNIX® or Linux. |
| Môi trường | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
